Powerworld R32 full inverter swimming pool heat pump series uses an inverter compressor; variable speed fan and logical control board, which can achieve energy saving, quick heating and cooling, and elevated accuracy of temperature control. It is a cost-effective option for air-source heat pumps.
•Mixed color design( customizable)
•LCD control panel (language customizable)
•Novelty screwless design
•Multiple noise reduction design
Specification
| Model | PW010-KZXYC-C | PW015-KZXYC-C | PW020-KZXYC-C | PW030-KZXYC-C | PW040-KZXYC-C | PW050-KZXYC-C |
| Advised pool volume (m3) | 15~30 | 20~40 | 25~50 | 30~60 | 40~75 | 55~100 |
| Operating air temperature (℃) | -7 ~43 | |||||
| Performance Condition: Air 27°C, Water 26°C, Humidity 80% | ||||||
| Heating capacity (kW) | 7.50~1.92 | 9.50~2.10 | 11.00~2.50 | 14.00~3.15 | 17.00~3.75 | 20.00~4.00 |
| Heating Capacity (Btu) | 25500~6528 | 32300~7140 | 37400~8500 | 47600~10710 | 57800~13090 | 68000~13600 |
| Consumed power (kW) | 1.36~0.15 | 1.73~0.16 | 2.00~0.19 | 2.54~0.24 | 3.1~0.28 | 3.64~0.31 |
| COP | 5.5~12.8 | 5.5~13.1 | 5.5~13.2 | 5.5~13.0 | 5.5~13.4 | 5.5~12.9 |
| COP at 50% capacity | 9.00 | 9.50 | 9.50 | 9.00 | 9.50 | 9.50 |
| Performance Condition: Air 15°C, Water 26°C, Humidity 70% | ||||||
| Heating capacity (kW) | 5.80~1.42 | 7.2~1.50 | 8.5~1.65 | 10.7~2.40 | 13.0~2.65 | 15.6~2.85 |
| Heating Capacity (Btu) | 19720~4828 | 24480~5100 | 28900~5610 | 36380~8160 | 44200~9010 | 53040~9690 |
| Consumed power (kW) | 1.28~0.22 | 1.60~0.23 | 1.89~0.25 | 2.38~0.37 | 2.89~0.41 | 3.47~0.44 |
| COP | 4.5~6.5 | 4.5~6.5 | 4.5~6.5 | 4.5~6.5 | 4.5~6.5 | 4.5~6.5 |
| COP at 50% capacity | 5.20 | 5.50 | 5.50 | 5.20 | 5.50 | 5.50 |
| Performance Condition: Air 35℃,Water 28℃, Humidity 80% | ||||||
| Cooling capacity (kW) | 4.0 | 5.2 | 6.0 | 7.2 | 8.6 | 10.1 |
| Sound pressure at 1m dB(A) | 38~48 | 38~48 | 40~50 | 42~51 | 43~52 | 43~53 |
| Sound pressure of 50% capacity at 1m dB(A) | 40 | 40 | 41 | 43 | 44 | 44 |
| Sound pressure at 10m dB(A) | 18~25 | 18~25 | 19~26 | 22~27 | 23~30 | 24~31 |
| Heat exchanger | Spiral titanium tube in PVC | |||||
| Casing | Metal Casing | |||||
| Refrigerant | R32 | |||||
| Power supply | 220V~230V/1 Ph/50Hz~60Hz | |||||
| Water Connection (mm) | Φ50 | |||||
| Rated input current at air 15℃ (A) | 5.6~1.0 | 7.0~1.0 | 8.3~1.1 | 10.5~1.6 | 12.6~1.8 | 15.2~1.9 |
| Advised water flux (m³/h) | 2~4 | 2~4 | 3~5 | 4~6 | 6~9 | 8~10 |
| Water Pressure Drop (max) kPa | 2 | 3 | 4 | 5 | 5 | 6 |
| Net weight/Gross weight (kg) | 48/53 | 50/55 | 53/58 | 62/67 | 67/72 | 67/72 |
| Product size (mm) | 912*360*610 | 980*370*760 | ||||
| Operating water temperature (℃) heating | 9 ~43 | |||||
| Operating water temperature (℃) cooling | 9 ~35 | |||||
